Mountain Biking Made Easy with Merida Big Seven 20

Exploring Trails the Fun Way

Ready to ride with our latest aluminium frame and trail-capable geometry. With agile 27.5" wheels, a 120 mm travel fork, an easy-to-use single ring drivetrain and hydraulic disc brakes, this is the way to mountain bike fun.

Why Choose the Merida Big Seven 20?

With hydraulic disc brakes, an easy-to-use single ring drivetrain, our latest TFS aluminium frame and a trail-ready 120 mm travel fork, the BIG SEVEN 20 MTB is ready to ride. Whether you need a versatile bike for weekend trail fun or a rugged way to get about, the updated, confidence inspiring geometry will have you covered while the agile 27.5" wheels are ideal for smaller riders.

Hardtail XC: Backbone of the Merida Range

When it comes to the demanding world of cross-country mountain biking, the classic hardtail remains one of the purest tools for the job. Our classic XC hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we have gained in over half a century of bike production and manufacturing. The BIG SEVEN and BIG NINE range represents the symbiosis between modern frame technology, attention to detail and craftsmanship that 'Made in Taiwan' stands for.

Buy from Your Local Store

Wollongong Bike Hub has been your local bicycle store for over 40 years. Our friendly and experienced team are on hand to help you find the best bike and accessories to suit your ride style and budget. This Merida mountain bike is just one of many awesome bikes in our range.

Key Features of the Merida Big Seven 20

• Updated TFS aluminium frame with clearance for 2.4" tyres
• Updated geometry for confident off-road handling
• Suntour suspension fork with 120 mm travel
• Shimano hydraulic disc brakes and 1x8-speed drivetrain
• MERIDA COMP CC 27.5" wheelset and Kenda tyres
• MERIDA finishing kit including size-tuned handlebars

Specifications Subject to Change without Prior Notice

BOTTOM BRACKET  Shimano UN101 LL123

BRAKES F: Shimano MT200 | R: Shimano MT200

CASSETTE Shimano CS-HG300-8; 11-45 ATC; 8 GER

CHAIN KMC Z8.3

CRANKSET Prowheel Epro-MD26S; 32 ATC; MAT Aluminium; 165mm on all sizes

DERAILLEUR REAR Shimano Essa RD-U2000-8; GS

FORK SR Suntour XCM32 NLO; Coil; 120 STR; lockout; 29x2,4" max. WHS

FRAME BIG.SEVEN TFS V; MAT aluminum; 29 WHS; 135x9 AST; BSA BBR; Smooth welding

GRIP  MERIDA EC

HANDLEBAR  MERIDA CC; MAT aluminium; 15 RHB; XXS/XS: 700WHB; S: 720 WHB

HANDLEBAR STEM  MERIDA COMP CC; MAT aluminium; 31.8 DSH; 7 ASD; 50mm

HEADSET  FSA NO.55R/57SC/57B

HUBS  F: Shimano TX505; 100x9 WHF; 32 SPH; Centerlock | R: Shimano TX505; 135x9 WHR; 32 SPH; Centerlock

PEDALS  VP VPE 536

RIM MERIDA COMP CC; 20 IWR; MAT aluminium

ROTOR FRONT  Shimano RT10; 160 mm

ROTOR REAR  Shimano RT10; 160 mm

SADDLE  MERIDA Sport

SEAT CLAMP  MERIDA COMP QR

SEAT POST  MERIDA COMP CC; MAT aluminium; 30.9 DSP; 0 SSB

SHIFTERS  F: | R: Shimano Essa SL-315-8R

SPOKES  Black steel

TYRES F: Kenda Booster; 27.5x2.4" | R: Kenda Booster; 27.5x2.4"
